diff --git a/library/adc-dac.dcm b/library/adc-dac.dcm
index 6fa0ea90..ab60a361 100644
--- a/library/adc-dac.dcm
+++ b/library/adc-dac.dcm
@@ -342,6 +342,12 @@ K 16bit ADC 8 Channels TSSOP I2C
 F http://www.ti.com/lit/ds/symlink/adc128d818.pdf
 $ENDCMP
 #
+$CMP ADS7828
+D 12-Bits, 8-Channels, ADC, I2C, TSSOP-16
+K I2C ADC 12Bits
+F http://www.ti.com/lit/ds/symlink/ads7828.pdf
+$ENDCMP
+#
 $CMP CA3300
 D Convertisseur A->D 6 bits rapide
 K ADC CAN
diff --git a/library/adc-dac.lib b/library/adc-dac.lib
index af6382b3..99456e78 100644
--- a/library/adc-dac.lib
+++ b/library/adc-dac.lib
@@ -1368,6 +1368,38 @@ X Ain0 16 -600 700 150 R 50 50 1 1 I
 ENDDRAW
 ENDDEF
 #
+# ADS7828
+#
+DEF ADS7828 U 0 40 Y Y 1 F N
+F0 "U" -200 600 50 H V C CNN
+F1 "ADS7828" 200 600 50 H V C CNN
+F2 "Housings_SSOP:TSSOP-16_4.4x5mm_Pitch0.65mm" 950 -700 50 H I C CNN
+F3 "" 0 0 50 H I C CNN
+$FPLIST
+ TSSOP*4.4x5mm*Pitch0.65mm*
+$ENDFPLIST
+DRAW
+S -250 550 250 -650 0 1 0 f
+S 250 -600 250 -600 0 1 0 N
+X CH0 1 -400 400 150 R 50 50 1 1 I
+X CH1 2 -400 300 150 R 50 50 1 1 I
+X CH2 3 -400 200 150 R 50 50 1 1 I
+X CH3 4 -400 100 150 R 50 50 1 1 I
+X CH4 5 -400 0 150 R 50 50 1 1 I
+X CH5 6 -400 -100 150 R 50 50 1 1 I
+X CH6 7 -400 -200 150 R 50 50 1 1 I
+X CH7 8 -400 -300 150 R 50 50 1 1 I
+X GND 9 0 -800 150 U 50 50 1 1 W
+X REF 10 400 0 150 L 50 50 1 1 B
+X COM 11 -400 -500 150 R 50 50 1 1 I
+X A0 12 400 -400 150 L 50 50 1 1 I
+X A1 13 400 -500 150 L 50 50 1 1 I
+X SCL 14 400 300 150 L 50 50 1 1 I
+X SDA 15 400 400 150 L 50 50 1 1 B
+X VDD 16 0 700 150 D 50 50 1 1 W
+ENDDRAW
+ENDDEF
+#
 # CA3300
 #
 DEF CA3300 U 0 40 Y Y 1 F N
